לוח אם – ASUS TUF GAMING B650M-E WIFI ATX AM5 DDR5 - צבע שחור
חדש
מק"ט: 90MB1GT0-M0EAY0
לוח אם איכותי מבית Asus, בעל תושבת AM5, ערכת שבבים B650, תאימות לזכרונות DDR5 ובעל יציאות HDMI ,DisplayPort.
₪825.00כולל מע"מ
במלאיפריסת תשלומים
₪825.00 לחודש
עד 2 תשלומים ללא ריבית
מפרט טכני
| תקופת אחריות | 3 שנים על ידי היבואן הרשמי |
| יצרן לוח אם | Asus |
| תמיכה במעבדים | AMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors* Refer to http://www.asus.com for CPU support list* |
| תמיכה בזיכרונות | x4 DIMM, Max. 192GB, DDR5 8000+(OC)/7800(OC)/7600(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600(OC)/5400(OC)/5200/5000/4800 ECC and Non-ECC, Un-buffered Memory* Dual Channel Memory Architecture |
| גרפיקה מובנית | 1x DisplayPort* 1x HDMI® port** Supports max. 8K@60Hz as specified in DisplayPort 1.4* Supports 4K@60Hz as specified in HDMI 2.1** VGA resolution support depends on processors' or graphic cards' resolution |
| חריצי הרחבה | :AMD Ryzen™ 9000 & 7000 Series Desktop Processors* 1x PCIe 4.0/3.0 x16 slot(s) :AMD Ryzen™ 8000 Series Desktop Processors* 1x PCIe 4.0 x16 slot (supports x8/x4 mode)** :AMD B650 Chipset 1x PCIe 4.0/3.0 x16 slot (supports x1 mode) 1x PCIe 4.0/3.0 x1 slots Please check PCIe bifurcation table on* support site (https://www.asus.com/support/FAQ/1037507/). Specifications vary by CPU types** To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals |
| USB | :Rear USB (Total 8 ports) 2x USB 10Gbps port(s) (1 x Type-A + 1 x USB Type-C®) 3x USB 5Gbps port(s) (3 x Type-A) 3x USB 2.0 port(s) (3 x Type-A) :Front USB (Total 7 ports) 1x USB 20Gbps connector (supports USB Type-C®) 1x USB 5Gbps header(s) support(s) 2 additional USB 5Gbps ports 2x USB 2.0 header(s) support(s) 4 additional USB 2.0 ports |
| ממשק אחסון | :Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports :AMD Ryzen™ 9000 & 7000 Series Desktop Processors M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode) M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) :AMD Ryzen™ 8000 Series Desktop Processors M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4/x2 mode)** :AMD B650 Chipset M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode) 4x SATA 6Gb/s ports AMD RAIDXpert2 Technology supports both* PCIe RAID 0/1/10 and SATA RAID 0/1/10 Specifications vary by CPU types** |
| שמע | Realtek 7.1 Surround Sound High Definition Audio CODEC* – Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking – Supports up to 24-Bit/192 kHz playback Audio Features – Audio Shielding – Premium audio capacitors – Dedicated audio PCB layers – Audio cover Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output** |
| כרטיס רשת קווי | 1x Realtek 2.5Gb Ethernet TUF LANGuard |
| מודול תקשורת אלחוטית | Wi-Fi 6E 2×2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax) Supports 2.4/5/6GHz frequency band* Bluetooth® v5.3** WiFi 6E 6GHz regulatory may vary between countries* The Bluetooth version may vary, please refer to the Wi-Fi module manufacturer's website for the latest specifications** |
| חיבורים פנימיים | :Fan and Cooling related x1 4-pin CPU Fan header(s) x1 4-pin CPU OPT Fan header(s) x1 4-pin AIO Pump header(s) x4 4-pin Chassis Fan header(s) :Power related x1 24-pin Main Power connector x1 8-pin +12V Power connector x1 4-pin +12V Power connector :Storage related x3 M.2 slots (Key M) x4 SATA 6Gb/s ports :USB x1 USB 20Gbps connector (supports USB Type-C®) x1 USB 5Gbps header(s) support(s) 2 additional USB 5Gbps ports x2 USB 2.0 header(s) support(s) 4 additional USB 2.0 ports :Miscellaneous x3 Addressable Gen 2 header(s) x1 Aura RGB header(s) x1 Clear CMOS header x1 COM Port header x1 Front Panel Audio header (AAFP) 20-3pin System Panel header with Chassis intrude function |
| חיבורים ויציאות | x2 USB 10Gbps port(s) (1 x Type-A + 1 x USB Type-C®) x3 USB 5Gbps port(s) (3 x Type-A) x3 USB 2.0 port(s) (3 x Type-A) x1 DisplayPort x1 HDMI® port x1 Wi-Fi Module x1 Realtek 2.5Gb Ethernet port x5 Audio jacks x1 BIOS FlashBack™ button |
| BIOS | 256Mb Flash ROM, UEFI AMI BIOS |
| תכונות ייחודיות | ASUS TUF PROTECTION DIGI+ VRM (- Digital power design with DrMOS) Enhanced DRAM Overcurrent Protection ESD Guards TUF LANGuard Overvoltage Protection SafeSlot Core+ Stainless-Steel Back I/O ASUS Q-Design M.2 Q-Latch Q-DIMM Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) Q-Slot ASUS Thermal Solution M.2 heatsink VRM heatsink design ASUS EZ DIY BIOS FlashBack™ button BIOS FlashBack™ LED ProCool Pre-mounted I/O shield SafeDIMM Aura Sync Aura RGB header(s) Addressable Gen 2 header(s) |
| תוכנות מצורפות | ASUS Exclusive Software Armoury Crate – Aura Creator – Aura Sync – Fan Xpert 4 – Power Saving – Two-Way AI Noise Cancellation AI Suite 3 – TurboV EVO – DIGI+ VRM – PC Cleaner TUF GAMING CPU-Z DTS Audio Processing MyAsus Norton Anti-virus software (Free Trial version) WinRAR UEFI BIOS ASUS EZ DIY – ASUS CrashFree BIOS 3 – ASUS EZ Flash 3 – ASUS UEFI BIOS EZ Mode |
| אביזרים כלולים | :Cables x2 SATA 6Gb/s cables :Miscellaneous x1 ASUS Wi-Fi moving antennas x1 TUF Gaming sticker x1 M.2 Rubber Package x1 Screw package for M.2 SSD :Documentation x1 TUF Certification card x1 User guide |
| תצורה | ATX Form Factor 12inch x 9.6inch ( 30.5 cm x 24.4 cm ) |
