| תקופת אחריות | 3 שנים על ידי היבואן הרשמי |
|---|
| יצרן לוח אם | Asus |
|---|
| מבוסס לוח אם | Intel |
|---|
| תושבת | LGA1700 |
|---|
| ערכת שבבים | H610 |
|---|
| סוג זיכרון לוח אם | DDR5 |
|---|
| גודל לוח אם | Micro-ATX |
|---|
| NVMe PCIe M.2 Connector | 1 |
|---|
| תמיכה במעבדים | Intel® Socket LGA1700 for Intel® Core™ 14th & 13th Gen Processors, Intel® Core™ 12th Gen, Pentium® Gold and Celeron® Processors*
Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
Refer to http://www.asus.com for CPU support list*
Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types** |
|---|
| תמיכה בזיכרונות | 2x DIMM slots, Max. 96GB, DDR5 5600/5400/5200/5000/4800 Non-ECC, Un-buffered Memory*
Dual Channel Memory Architecture
Supports Intel® Extreme Memory Profile (XMP)
Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/.
Non-ECC, un-buffered DDR5 memory supports On-Die ECC function* |
|---|
| גרפיקה מובנית | 1x VGA port
1x HDMI™ port**
Graphics specifications may vary between CPU types. Please refer to http://www.intel.com for any updates*
Supports 4K@60Hz as specified in HDMI 2.1** |
|---|
| חריצי הרחבה | Intel® Core™ Processors (14th & 13th & 12th Gen)
1x PCIe 4.0 x16 slot
Intel® H610 Chipset
1x PCIe 3.0 x1 slot
To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals |
|---|
| USB | Rear USB (Total 6 ports)
2x USB 3.2 Gen 1 (5G) ports (2 x Type-A)
4x USB 2.0 ports (4 x Type-A) :Front USB (Total 4 ports)
1x USB 3.2 Gen 1 (5G) header supports 2 additional USB 3.2 Gen 1 ports
1x USB 2.0 header supports 2 additional USB 2.0 ports |
|---|
| ממשק אחסון | Total supports 1 x M.2 slot and 4 x SATA 6Gb/s ports
Intel® H610 Chipset
M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 mode)
4x SATA 6Gb/s ports |
|---|
| שמע | Realtek 7.1 Surround Sound High Definition Audio CODEC*
Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
Supports up to 24-Bit/192 kHz playback :Audio Features
– Audio Shielding
– Premium audio capacitors
– Dedicated audio PCB layers
A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output* |
|---|
| כרטיס רשת קווי | 1x Realtek 1Gb Ethernet |
|---|
| חיבורים פנימיים | :Fan and Cooling related
1x 4-pin CPU Fan header
2x 4-pin Chassis Fan headers :Power related
1x 24-pin Main Power connector
1x 8-pin +12V Power connector :Storage related
1x M.2 slot (Key M)
4x SATA 6Gb/s ports :USB
1x USB 3.2 Gen 1 (5G) header supports 2 additional USB 3.2 Gen 1 ports
1x USB 2.0 header supports 2 additional USB 2.0 ports :Miscellaneous
1x RGB header
1x Clear CMOS header
1x Front Panel Audio header (AAFP)
1x COM Port header
1x S/PDIF Out header
1x Speaker header
1x SPI TPM header (14-1pin)
1x 10-1 pin System Panel header |
|---|
| חיבורים ויציאות | 2x USB 3.2 Gen 1 (5G) ports (2 x Type-A)
4x USB 2.0 ports (4 x Type-A)
1x VGA port
1x HDMI™ port
1x Realtek 1Gb Ethernet port
3x Audio jacks
1x PS/2 Keyboard/Mouse combo port |
|---|
| BIOS | 128Mb Flash ROM, UEFI AMI BIOS |
|---|
| תכונות מיוחדות | ASUS 5X PROTECTION III
– DIGI+ VRM
– LANGuard
– Overvoltage Protection
– SafeSlot Core
– Stainless-Steel Back I/O
ASUS Q-Design
– Q-DIMM
– Q-LED Core
– Q-Slot
ASUS Thermal Solution
– Aluminum heatsink design
ASUS Lighting Control
– RGB header |
|---|
| תוכנות מצורפות | ASUS Exclusive Software
Armoury Crate
– Fan Xpert 2+
AI Suite 3
– EPU
– DIGI+ VRM
– PC Cleaner
ASUS CPU-Z
Norton 360 Deluxe (60 Days Free Trial)
WinRAR
UEFI BIOS
ASUS EZ DIY
– ASUS CrashFree BIOS 3
– ASUS EZ Flash 3
– ASUS UEFI BIOS EZ Mode |
|---|
| אביזרים כלולים | :Cables
2x SATA 6Gb/s cables :Miscellaneous
1x I/O Shield
1x M.2 Anchor :Documentation
1x User guide |
|---|
| תצורה | micro-ATX Form Factor
9.2inch x 8.0 inch ( 23.4 cm x 20.3 cm ) |
|---|
| קישור לאתר היצרן | https://www.asus.com/motherboards-components/motherboards/prime/prime-h610m-k/ |
|---|
