| תקופת אחריות |
3 שנים על ידי היבואן הרשמי
|
| מבוסס |
Intel
|
| תושבת |
LGA1700
|
| ערכת שבבים |
B760
|
| סוג זיכרון לוח אם |
DDR5
|
| גודל |
Micro-ATX
|
| NVMe PCIe M.2 Connector |
2
|
| קישוריות |
WIFI & Bluetooth
|
| תמיכה במעבדים |
Intel® Socket LGA1700 for 13th Gen Intel® Core™ & 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors*
Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
Refer to http://www.asus.com for CPU support list*
Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types**
|
| תמיכה בזיכרונות |
x4 DIMM slots, Max. 128GB, DDR5 7200+(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600/ 5400/5200/5000/4800MHz Non-ECC, Un-buffered Memory*
Dual Channel Memory Architecture
Supports Intel® Extreme Memory Profile (XMP)
OptiMem II
Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/
Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.
|
| גרפיקה מובנית |
x1 DisplayPort**
x2 HDMI® ports***
Graphics specifications may vary between CPU types. Please refer to http://www.intel.com for any updates*
Supports max. 4K@60Hz as specified in DisplayPort 1.4**
Supports 4K@60Hz as specified in HDMI® 2.1***
|
| חריצי הרחבה |
Intel® CoreTM Processors (14th & 13th & 12th Gen)
1x PCIe 4.0 x16 slot
Intel® B760 Chipset
1x PCIe 4.0 x16 slot (supports x4 mode)
1x PCIe 4.0 x16 slot (supports x1 mode)
Note: To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals
|
| USB |
Rear USB (Total 6 ports)
2x USB 3.2 Gen 2 ports (2 x Type-A )
4x USB 2.0 ports (4 x Type-A)
Front USB (Total 10 ports)
2x USB 3.2 Gen 1 headers support 4 additional USB 3.2 Gen 1 ports
1x USB 3.2 Gen 1 connector (supports USB Type-C®)
2x USB 2.0 headers support 4 additional USB 2.0 ports
1x USB 2.0 header supports 1 additional USB 2.0 port
|
| ממשק אחסון |
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
x4 SATA 6Gb/s ports
.Intel® Rapid Storage Technology supports SATA RAID 0/1/5/10*
|
| שמע |
Realtek 7.1 Surround Sound High Definition Audio CODEC*
Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking –
Supports up to 24-Bit/192 kHz playback –
Audio Features
Audio Shielding –
Premium audio capacitors –
Dedicated audio PCB layers –
.A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output*
|
| כרטיס רשת קווי |
1x Realtek 2.5Gb Ethernet
|
| מודול תקשורת אלחוטית |
Wi-Fi 6
2×2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax)
Supports 2.4/5GHz frequency band
Bluetooth v5.2
.The Bluetooth version may vary, please refer to the Wi-Fi module manufacturer's website for the latest specifications*
|
| חיבורים פנימיים |
x1 4-pin CPU Fan header
x1 4-pin CPU OPT Fan header
x2 4-pin Chassis Fan headers
x1 24-pin Main Power connector
x1 8-pin +12V Power connector
x2 M.2 slots (Key M)
x4 SATA 6Gb/s ports
x2 USB 3.2 Gen 1 headers support 4 additional USB 3.2 Gen 1 ports
x1 USB 3.2 Gen 1 connector (supports USB Type-C®)
x2 USB 2.0 headers support 4 additional USB 2.0 ports
x1 USB 2.0 header supports 1 additional USB 2.0 port
x3 Addressable Gen 2 headers
x1 Aura RGB header
x1 Clear CMOS header
x1 COM Port header
x1 Front Panel Audio header (AAFP)
x1 LPT header
x1 S/PDIF Out header
x 1SPI TPM header (14-1pin)
x1 20-3 pin System Panel header with Chassis intrude function
|
| חיבורים ויציאות |
x2 USB 3.2 Gen 2 ports (2 x Type-A )
x4 USB 2.0 ports (4 x Type-A)
x1 DisplayPort
x2 HDMI® ports
x1 Wi-Fi Module
x1 Realtek 2.5Gb Ethernet port
x3 Audio jacks
x1 PS/2 Keyboard/Mouse combo port
|
| תכונות מיוחדות |
DIGI+ VRM
LANGuard
Overvoltage Protection
SafeSlot Core+
Stainless-Steel Back I/O
Q-DIMM
Q-LED Core
Q-Slot
M.2 heatsink
VRM heatsink design
ProCool
Aura RGB header
Addressable Gen 2 headers
|
| תוכנות מצורפות |
Armoury Crate
Aura Creator
Aura Sync
Fan Xpert 2+
Power Saving
AI Suite 3
Digi+ VRM
PC Cleaner
ASUS CPU-Z
MyAsus
Norton Deluxe (60 Days Free Trial)
WinRAR
ASUS EZ DIY
ASUS CrashFree BIOS 3
ASUS EZ Flash 3
ASUS UEFI BIOS EZ Mode
|
| אביזרים כלולים |
x2 SATA 6Gb/s cables
x1 I/O Shield
x 1M.2 Rubber Package
x1 Screw package for M.2 SSD
x1 ACC Express Activation Key Card
x1 User guide
|
| תצורה |
mATX Form Factor
9.6inch x 9.6 inch ( 24.4 cm x 24.4 cm )
|
| קישור לאתר היצרן |
https://www.asus.com/motherboards-components/motherboards/prime/prime-b760m-a-wifi/
|
