| תקופת אחריות |
3 שנים על ידי היבואן הרשמי
|
| יצרן לוח אם |
Asus
|
| מבוסס לוח אם |
AMD
|
| תושבת |
AM5
|
| ערכת שבבים |
X870
|
| סוג זיכרון לוח אם |
DDR5
|
| גודל לוח אם |
ATX
|
| NVMe PCIe M.2 Connector |
5
|
| קישוריות |
WIFI & Bluetooth
|
| תמיכה במעבדים |
AMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors*
Refer to https://www.asus.com/support/download-center/ for CPU support list*
|
| תמיכה בזיכרונות |
4x DIMM slots, max. 256GB, DDR5
Supports up to
8000MT/s(OC) with Ryzen™ 9000 Series Processors+
8400MT/s(OC) with Ryzen™ 8000 Series Processors+
8000MT/s(OC) with Ryzen™ 7000 Series Processors+
ECC and Non-ECC Un-buffered DIMM*
Dual Channel Memory Architecture
Supports AMD EXTended Profiles for Overclocking (EXPO™)
NitroPath DRAM Technology
ASUS Enhanced Memory Profile (AEMP)
Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/download-center/.
Non-ECC, Un-buffered DDR5 Memory supports On-Die ECC function*
|
| גרפיקה מובנית |
1x HDMI™ port**
2x USB4® (40Gbps) ports support USB Type-C® display outputs***
Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications*
Supports max. 4K@60Hz as specified in HDMI 2.1**
Supports max. 4K@60Hz as specified in DisplayPort 1.4a***
VGA resolution support depends on processors' or graphic cards' resolution****
|
| חריצי הרחבה |
AMD Ryzen™ 9000 & 7000 Series Desktop Processors*
1x PCIe 5.0 x16 slot (supports x16 mode)
AMD Ryzen™ 8000 Series Desktop Processors*
1x PCIe 4.0 x16 slot (supports x8/x4 mode)**
AMD X870E Chipset
1x PCIe 4.0 x16 slot (supports x4 mode)
Please check PCIe bifurcation table in support site (https://www.asus.com/support/FAQ/1037507/)*
Specifications vary by CPU types**
To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals
|
| USB |
Rear USB (Total 13 ports)
2x USB4® (40Gbps) ports(2 x USB Type-C®)
1x USB 20Gbps port (1 x USB Type-C® with up to 30W PD Fast-charge)**
10x USB 10Gbps ports (9 x Type-A + 1 x USB Type-C®)
Front USB (Total 11 ports)
1x USB 20Gbps connector (supports USB Type-C®)
2x USB 5Gbps headers support additional 4 USB 5Gbps ports
3x USB 2.0 headers support additional 6 USB 2.0 ports
USB Type-C® power delivery output: 5V/3A*
USB Type-C® power delivery output: 5V/9V max. 3A, 12V max 2.5A, 15V max. 2.0A**
|
| ממשק אחסון |
Total supports 5 x M.2 slots and 4 x SATA 6Gb/s ports*
AMD Ryzen™ 9000 & 7000 Series Desktop Processors*
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)**
M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)**
AMD Ryzen™ 8000 Series Desktop Processors*
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
M.2_2 slot (Key M), type 2242/2260/2280 (Not supports)***
M.2_3 slot (Key M), type 2242/2260/2280/22110 (Not supports)***
AMD X870E Chipset
M.2_4 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
M.2_5 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
4x SATA 6Gb/s ports
AMD RAIDXpert2 Technology supports both PCIe RAID 0/1/5/10 and SATA RAID 0/1/5/10. RAID 5 Funciton is only supportted by AMD Ryzen™ 9000series CPU*
M.2_2 & M.2_3 slots share bandwidth with PCIEX16(G5). When M.2_2 & M.2_3 are occupied with SSD devices, PCIEX16(G5) will run x8 only**
M.2_2 & M.2_3 will be disabled when using AMD Ryzen™ 8000 Series Desktop Processors***
|
| שמע |
ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080*
– Impedance sense for front and rear headphone outputs
– Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking
– High quality 120 dB SNR stereo playback output and 110 dB SNR recording input
– Supports up to 32-Bit/384 kHz playback
:Audio Features
– Audio Shielding
– Savitech SV3H712 AMP
– Gold-plated audio jacks
– Rear optical S/PDIF out port
– Premium audio capacitors
– Audio cover
The LINE OUT port on the rear panel does not support spatial audio. If you wish to use spatial audio, make sure to connect your audio output device to the audio jack on the front panel of your chassis or use a USB interface audio device
|
| כרטיס רשת קווי |
1x Realtek 5Gb Ethernet
ASUS LANGuard
|
| מודול תקשורת אלחוטית |
Wi-Fi 7*
2×2 Wi-Fi 7 (802.11be)
Supports 2.4/5/6GHz frequency band**
Support Wi-Fi 7 320MHz bandwidth, up to 6.5Gbpstransfer rate.
Bluetooth® v5.4***
Wi-Fi features may vary depending on the operating system*
For Windows 11, Wi-Fi 7 will require24H2 or later version for full functions, Windows 11 21H2/22H2/23H2 only support Wi-Fi 6E
For Windows 10, please note that no driver is available, refer to the Wi-Fi chipset vendor's website for details
Wi-Fi 6GHz frequency band and bandwidth regulatory may vary between countries**
The Bluetooth® version may vary, please refer to the Wi-Fi module manufacturer's website for the latest specifications***
|
| חיבורים פנימיים |
:Fan and Cooling related
1x 4-pin CPU Fan header
1x 4-pin CPU OPT Fan header
1x 4-pin AIO Pump header
5x 4-pin Chassis Fan headers
:Power related
1x 24-pin Main Power connector
2x 8-pin +12V CPU Power connectors
:Storage related
5x M.2 slots (Key M)
4x SATA 6Gb/s ports
:USB
1x USB 20Gbps connector (supports USB Type-C®)
2x USB 5Gbps headers support additional 4 USB 5Gbps ports
3x USB 2.0 headers support additional 6 USB 2.0 ports
:Miscellaneous
3x Addressable Gen 2 headers
1x CPU Over Voltage jumper
1x FlexKey button
1x Front Panel Audio header (F_AUDIO)
1x Start button
1x 10-1 pin System Panel header
1x Thermal Sensor header
|
| חיבורים ויציאות |
2x USB4® (40Gbps) ports (2 x USB Type-C®)
1x USB 20Gbps port (1 x USB Type-C® with up to 30W PD Fast-charge)
10x USB 10Gbps ports (9 x Type-A + 1 x USB Type-C®)
1x HDMI™ port
1x Wi-Fi Module
1x Realtek 5Gb Ethernet
2x Gold-plated audio jacks
1x Optical S/PDIF out port
1x BIOS FlashBack™ button
1x Clear CMOS button
|
| BIOS |
256Mb Flash ROM, UEFI AMI BIOS
|
| תכונות מיוחדות |
+Extreme Engine Digi
– 5K Black Metallic Capacitors
ASUS Q-Design
– M.2 Q-Latch
– M.2 Q-Release
– M.2 Q-Slide
– PCIe Slot Q-Release Slim (with PCIe SafeSlot)
– Q-Antenna
– Q-Code
– Q-Dashboard
– Q-DIMM
– Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
– Q-Slot
ASUS Thermal Solution
– M.2 heatsinks
– M.2 heatsink backplate
– VRM heatsink design
ASUS EZ DIY
– BIOS FlashBack™ button
– BIOS FlashBack™ LED
– Clear CMOS button
– ProCool II
– Pre-mounted I/O shield
– SafeSlot
– SafeDIMM
Aura Sync
– Addressable Gen 2 headers
|
| תוכנות מצורפות |
ROG Exclusive Software
– ROG CPU-Z
– Dolby Atmos
ASUS Exclusive Software
Armoury Crate
– AIDA64 Extreme (60 days free trial)
– Aura Creator
– Aura Sync
– Fan Xpert 4 (with AI Cooling II)
– GameFirst
– HWiNFO
– Power Saving
ASUS Driver Hub
ASUS GlideX
TurboV Core
USB Wattage Watcher
Adobe Creative Cloud (Free Trial)
Norton 360 for Gamers (60 Days Free Trial)
WinRAR (40 Days Free Trial)
UEFI BIOS
AI Overclocking Guide
ASUS EZ DIY
– ASUS CrashFree BIOS 3
– ASUS EZ Flash 3
– ASUS UEFI
BIOS EZ Mode
– ASUS
MyHotkey
Dynamic OC Switcher
FlexKey
|
| אביזרים כלולים |
:Cables
2x SATA 6Gb/s cables
:Additional Cooling Kit
1x Thermal pad for M.2 22110
:Miscellaneous
1x ASUS Wi-Fi moving antennas
1x Cable ties pack
1x M.2 Q-Latch package
2 x M.2 Q-Slides
1x ROG key chain
1x ROG Strix stickers
5x M.2 Rubbers
:Documentation
1x Quick start guide
|
| תצורה |
ATX Form Factor
12inch x 9.6 inch ( 30.5 cm x 24.4 cm )
|
| קישור לאתר היצרן |
https://rog.asus.com/motherboards/rog-strix/rog-strix-x870e-e-gaming-wifi/
|
