| תקופת אחריות |
3 שנים על ידי היבואן הרשמי
|
| יצרן לוח אם |
Asus
|
| מבוסס לוח אם |
AMD
|
| תושבת |
AM5
|
| ערכת שבבים |
X870
|
| סוג זיכרון לוח אם |
DDR5
|
| גודל לוח אם |
ATX
|
| NVMe PCIe M.2 Connector |
5
|
| קישוריות |
WIFI & Bluetooth
|
| תמיכה במעבדים |
AMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors*
Refer to https://www.asus.com/support/download-center/ for CPU support list*
|
| תמיכה בזיכרונות |
4x DIMM slots, max.256GB, DDR5
Supports up to
8200MT/s(OC) with Ryzen™ 9000 Series Processors+
8600MT/s(OC) with Ryzen™ 8000 Series Processors+
8000MT/s(OC) with Ryzen™ 7000 Series Processors+
ECC and Non-ECC, Un-buffered Memory*
Dual channel memory architecture
Supports AMD Extended Profiles for Overclocking (EXPO™)
NitroPath DRAM Technology
ASUS Enhanced Memory Profile (AEMP)
Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/download-center/.
Non-ECC, un-buffered DDR5 memory supports On-Die ECC function*
|
| גרפיקה מובנית |
1x HDMI™ port*
2x USB4® (40Gbps) ports support USB Type-C® display outputs**
Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications
VGA resolution support depends on processors' or graphic cards' resolution
Supports 4K@60Hz as specified in HDMI 2.1*
Supports max. 4K@60Hz as specified in DisplayPort 1.4a**
|
| חריצי הרחבה |
AMD Ryzen™ 9000 & 7000 Series Desktop Processors*
2x PCIe 5.0 x16 slots with Q-Release Slim (supports x16 or x8/x8** or x8/x4/x4 modes*****)
When both PCIEX16_1 and PCIEX16_2 are in use, they will each run in x8 mode**
When M.2_2 is enabled, but M.2_3 is not in use, PCIEX16_1 will run in x8 mode and PCIEX16_2 will be disabled***
When M.2_3 is enabled, but M.2_2 is not in use, PCIEX16_1 will run in x8 mode and PCIEX16_2 will run in x4 mode****
When both M.2_2 and M.2_3 are enabled, PCIEX16_1 will run in x8 mode and PCIEX16_2 will be disabled*****
AMD Ryzen™ 8700 & 8600 & 8400 Series Desktop Processors*
2x PCIe 4.0 x16 slots with Q-Release Slim (only supports PCIEx16_1 & total bandwidth for x8, PCIEx16_2 will be disabled)
AMD Ryzen™ 8500 & 8300 Series Desktop Processors*
2x PCIe 4.0 x16 slots with Q-Release Slim (only supports PCIEx16_1 & total bandwidth for x4, PCIEx16_2 will be disabled)
Please check the PCIe bifurcation table on the support site (https://www.asus.com/support/FAQ/1037507/)*
To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported
|
| USB |
Rear USB (Total 10 ports)
2x USB4® (40Gbps) ports (2 x USB Type-C®)
8x USB 10Gbps ports (6 x Type-A + 2 x USB Type-C®)
Front USB (Total 10 ports)
1x USB 20Gbps (supports USB Type-C® with up to 60W PD/QC4+)*
1x USB 20Gbps connector (supports USB Type-C®)
2x USB 5Gbps headers support 4 additional USB 5Gbps ports
2x USB 2.0 headers support 4 additional USB 2.0 ports
USB Type-C® power delivery output: max. 5V/3A
USB Type-C® power delivery output: 5/9/15/20V max. 3A, PPS:3.3–21V max. 3A*
|
| ממשק אחסון |
Supports 5 x M.2 slots and 1 x SlimSAS connector and 4 x SATA 6Gb/s ports*
AMD Ryzen™ 9000 & 7000 Series Desktop Processors
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
AMD Ryzen™ 8000 Series Desktop Processors
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
M.2_2 slot (Key M), type 2242/2260/2280 (Not supports)
M.2_3 slot (Key M), type 2242/2260/2280 (Not supports)
AMD X870E Chipset
M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
M.2_5 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
SlimSAS slot supports PCIe 4.0 x4 mode.
4x SATA 6Gb/s ports
When both PCIEX16_1 and PCIEX16_2 are in use, they will each run in x8 mode**
When M.2_2 is enabled, but M.2_3 is not in use, PCIEX16_1 will run in x8 mode and PCIEX16_2 will be disabled***
When M.2_3 is enabled, but M.2_2 is not in use, PCIEX16_1 will run in x8 mode and PCIEX16_2 will run in x4 mode****
When both M.2_2 and M.2_3 are enabled, PCIEX16_1 will run in x8 mode and PCIEX16_2 will be disabled*****
AMD RAIDXpert2 Technology
Ryzen™ 9000 Series Processors: RAID 0/1/5/10
Ryzen™ 8000 Series Processors: RAID 0/1
Ryzen™ 7000 Series Processors: RAID 0/1/10
|
| שמע |
ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082*
– Impedance sense for front and rear headphone outputs
– Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking
– High quality 120 dB SNR stereo playback output and 110 dB SNR recording input
– Supports up to 32-Bit/384 kHz playback on front panel
:Audio Features
– SupremeFX Shielding Technology
– ESS® ES9219 QUAD DAC
– Gold-plated audio jacks
– Rear optical S/PDIF out port
– Premium audio capacitors
A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output*
The LINE OUT port on the rear panel does not support spatial audio. If you wish to use spatial audio, make sure to connect your audio output device to the audio jack on the front panel of your chassis or use a USB interface audio device
|
| כרטיס רשת קווי |
1x Intel® 2.5Gb Ethernet
1x Realtek 5Gb Ethernet
ASUS LANGuard
|
| מודול תקשורת אלחוטית |
Wi-Fi 7 (Qualcomm QCNCM865 or MediaTek MT7927)*
2×2 Wi-Fi 7** (802.11be)
Supports 2.4/5/6GHz frequency band***
Supports Wi-Fi 7 320MHz bandwidth
Bluetooth® v5.4****
The actual Wi-Fi module that comes with this motherboard may vary, please refer to the label on the product for more details*
Wi-Fi features may vary depending on the operating system**
For Windows 11, Wi-Fi 7 will require 24H2 or later version for full functions, Windows 11 21H2/22H2/23H2 only support Wi-Fi 6E
For Windows 10, please note that no driver is available, refer to the Wi-Fi chipset vendor's website for details
Wi-Fi 6GHz frequency band and bandwidth regulatory may vary between countries***
The Bluetooth® version may vary, please refer to the Wi-Fi module manufacturer's website for the latest specifications****
|
| חיבורים פנימיים |
:Fan and Cooling Related
1x 4-pin CPU Fan header
1x 4-pin CPU OPT Fan header
1x 4-pin AIO Pump header
4x 4-pin Chassis Fan headers
1x W_PUMP+ header
:Power Related
1x 24-pin Main Power connector
2x 8-pin +12V CPU Power connector
1x 8-pin PCIe Power connector
:Storage Related
5x M.2 slots (Key M)
1x SlimSAS connector
4x SATA 6Gb/s ports
:USB
2x USB 20Gbps connectors (support USB Type-C® )
2x USB 5Gbps headers support 4 additional USB 5Gbps ports
2x USB 2.0 headers support 4 additional USB 2.0 ports
:Miscellaneous
3x Addressable Gen2 headers
1x Alteration PCIe mode switch
1x FlexKey button
1x Front Panel Audio header (F_AUDIO)
1x ReTry button
1x Start button
1x 10-1 pin System Panel header
1x Thermal Sensor header
1x LN2 Mode jumper
|
| חיבורים ויציאות |
2x USB4® (40Gbps) ports (2 x USB Type-C®)
8x USB 10Gbps ports (6 x Type-A + 2 x USB Type-C®)
1x HDMI™ port
1x Wi-Fi module
1x Intel® 2.5Gb Ethernet port
1x Realtek 5Gb Ethernet port
2x Gold-plated audio jacks
1x Optical S/PDIF out port
1x BIOS FlashBack™ button
1x Clear CMOS button
|
| BIOS |
256Mb Flash ROM, UEFI AMI BIOS
|
| תכונות מיוחדות |
Extreme OC Kit
– FlexKey button
– LN2 Mode
– ReTry button
– Start button
Extreme Engine Digi+
– 10K Black metallic capacitors
– MicroFine alloy choke
ASUS Q-Design
– M.2 Q-Latch
– M.2 Q-Release
– M.2 Q-Slide
– Q-Release Slim (with PCIe SafeSlot)
– Q-Antenna
– Q-Code
– Q-Connector
– Q-Dashboard
– Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
– Q-Slot
ASUS Thermal Solution
– M.2 heatsink backplate
– M.2 heatsink
– VRM heatsink design
– Metal backplate
ASUS EZ DIY
– Backplate
– BIOS FlashBack™ button
– Clear CMOS button
– ProCool II
– Pre-mounted I/O shield
– SafeSlot
– SafeDIMM
Aura Sync
– Addressable Gen2 header(s)
Front Panel USB 20Gbps with Quick Charge 4+ Support
– Support: up to 60W fast charging and USB Wattage Watcher*
– Output: 5/9/15/20V max. 3A, PPS:3.3–21V max. 3A
– Compatible with PD3.0 and PPS
To support 60W, please install the power cable to the 8-pin PCIe power connector or else only 27W will be supported*
|
| תוכנות מצורפות |
ROG Exclusive Software
– ROG CPU-Z
– Dolby Atmos
– Internet Security (1-year full version)
– Polymo Lighting II
ASUS Exclusive Software
Armoury Crate
– AIDA64 Extreme (1 year full version)
– Aura Creator
– Aura Sync
-Fan Xpert 4 (with AI Cooling II)
– GameFirst
– HWiNFO
– Power Saving
ASUS DriverHub
ASUS GlideX
USB Wattage Watcher
TurboV Core
WinRAR (40 Days Free Trial)
Adobe Creative Cloud (Free Trial)
UEFI BIOS
AI Overclocking Guide
ASUS EZ DIY
– ASUS CrashFree BIOS 3
– ASUS EZ Flash 3
– ASUS UEFI BIOS EZ Mode
– ASUS MyHotkey
FlexKey
|
| אביזרים כלולים |
:Cables
1x ARGB RGB extension cable
4x SATA 6Gb/s cables
:Miscellaneous
1x ASUS WiFi Q-Antenna
1x Q-connector
2x M.2 Q-Latch package
3x M.2 Q-Slide package
5x M.2 rubber package
1x ROG stickers
1x ROG thank you card
1x ROG Bottle Opener
:Installation Media
1x USB drive with utilities and drivers
:Documentation
1x Quick start guide
|
| תצורה |
ATX Form Factor
12inch x 9.6 inch ( 30.5 cm x 24.4 cm )
|
| קישור לאתר היצרן |
https://rog.asus.com/motherboards/rog-crosshair/rog-crosshair-x870e-hero/
|
