| תקופת אחריות |
3 שנים על ידי היבואן הרשמי
|
| יצרן לוח אם |
Asus
|
| מבוסס לוח אם |
AMD
|
| תושבת |
sTR5
|
| ערכת שבבים |
TRX50
|
| סוג זיכרון לוח אם |
ECC DDR5
|
| גודל לוח אם |
CEB
|
| NVMe PCIe M.2 Connector |
3
|
| קישוריות |
WIFI & Bluetooth
|
| תמיכה במעבדים |
AMD Socket sTR5 for Ryzen™ Threadripper™ PRO 9000 & 7000 WX-Series and Ryzen™ Threadripper™ 9000 & 7000 Series Processors **
*Refer to http://www.asus.com for CPU support list.
**System boot may take longer with Threadripper™ 9000 series CPUs due to memory calibration.This behavior is normal. Please allow sufficient time for the process to complete
|
| תמיכה בזיכרונות |
4 x DIMM slots, DDR5, ECC Registered Memory*
4 Channel Memory Architecture
* Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/
|
| חריצי הרחבה |
AMD Ryzen™ Threadripper™ PRO 9000 & 7000 WX-Series and Ryzen™ Threadripper™ 9000 & 7000 Series Processors
2x PCIe 5.0 x16 slots
1x PCIe 5.0 x16 slot(x8 mode)
1x PCIe 4.0 x16 slot
1x PCIe 4.0 x16 slot(x4 mode)
Please check the PCIe bifurcation table on the support site (https://www.asus.com/support/FAQ/1037507/)*
|
| USB |
Rear USB (Total 9 ports)
1x USB 20Gbps port (1 x USB Type-C®)
6x USB 10Gbps ports (6 x Type-A )
2x USB 2.0 ports (2 x Type-A )
Front USB (Total 7 ports)
1x USB 20Gbpsconnector (supports USB Type-C® with up to 27W PD/QC4+)
1x USB 5Gbps header supports 2 additional USB 5G ports
2x USB 2.0 headers support additional 4 USB 2.0 ports
|
| ממשק אחסון |
Total supports 3 x M.2 slots, 4 x SATA 6Gb/s ports
AMD Ryzen™ Threadripper™ PRO 9000 & 7000 WX-Series and Ryzen™ Threadripper™ 9000 & 7000 Series Processors
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
AMD TRX50 Chipset
M.2_3 slot (Key M), type 2280(supports PCIe 4.0 x4 mode)
4x SATA 6Gb/s ports
1x SlimSAS slot supports PCIe 4.0 x4 mode NVMe device
AMD RAIDXpert2 Technology supports both PCIe RAID 0/1/5/10 and SATA RAID 0/1/5/10*
|
| שמע |
Realtek ALC1220P Surround Sound High Definition Audio CODEC*
– Impedance sense for front and rear headphone outputs
– Internal audio Amplifier to enhance the highest quality sound for headphone and speakers
– Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
– High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)
– Supports up to 32-Bit/192 kHz playback"
:Audio Features
– Audio Shielding
– Rear optical S/PDIF out port
– Dedicated audio PCB layers
– Unique de-pop circuit
A chassis with an HD audio module in the front panel is required to support 5.1 Surround Sound audio output*
This motherboard will only support up to 5.1 Surround Sound due to the number of audio ports available on the motherboard*
|
| כרטיס רשת קווי |
1x Marvell® AQtion 10Gb Ethernet
1x Intel® I226-LM 2.5Gb Ethernet
|
| מודול תקשורת אלחוטית |
Wi-Fi 7*
2×2 Wi-Fi 7 (802.11be)
Supports 2.4/5/6GHz frequency band**
Support Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate
Bluetooth® v5.4***
Wi-Fi features may vary depending on the operating system*
For Windows 11, Wi-Fi 7 will require SV3 or later version for full functions, Windows 11 SV1/2 only support Wi-Fi 6E
For Windows 10, please note that no driver is available , please refer to the Wi-Fi chipset vendor's website for details
Wi-Fi 6GHz frequency band and bandwidth regulatory may vary between countries**
The Bluetooth® version may vary, please refer to the Wi-Fi module manufacturer's website for the latest specifications***
|
| חיבורים פנימיים |
:Fan and Cooling related
1x 4-pin CPU Fan header
1x 4-pin CPU OPT Fan header
1x W_PUMP+ header
4x 4-pin Chassis Fan headers
2x 4-pin VRM Fan header (with VRM FAN onboard)
:Power related
2x 24-pin Main Power connectors
2x 8-pin +12V Power connectors
2x 8-pin PCIe to CPU power connectors
1x 6-pin PCIe Power connector
1x 8-pin PCIe Power connector
:Storage related
3x M.2 slots (Key M) 4 x SATA 6Gb/s ports
1x SlimSAS port
:USB
1x USB 20Gbps connector supports USB Type-C®
1x USB 5Gbps header supports 2 additional USB 5Gbps ports
2x USB 2.0 headers support additional 4 USB 2.0 ports
:Miscellaneous
1x BMC header
1x COM Port header
1x USB4 header
1x FlexKey button
1x Front panel audio header (F_AUDIO)
1x Start button
1x Safe boot button
1x ReTry button
1x LN2 mode jumper
1x Slow mode switch
1x SPI TPM header (14-1pin)
1x 10-1 pin system panel header
1x Chassis intrusion header
1x Thermal Sensor header
|
| חיבורים ויציאות |
1x USB 20Gbps port (1 x USB Type-C®)
6x USB 10Gbps ports (6 x Type-A)
2x USB 2.0 port (2 x Type-A)
1x Wi-Fi Module
1x Marvell® AQtion 10Gb Ethernet port
1x Intel® 2.5Gb Ethernet port
2x Audio jacks
1x Optical S/PDIF out port
1x BIOS FlashBack™ button
1x Clear CMOS button
|
| BIOS |
256Mb Flash ROM, UEFI AMI BIOS
|
| תכונות מיוחדות |
:ASUS Q-Design
– Q-Code
– M.2 Q-Latch
– Q-Connector
– Q-DIMM
– Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
– Q-Slot
ASUS Thermal Solution
– M.2 heatsink and onboard thermal pads
– VRM heatsink design with active fans
:ASUS EZ DIY
– BIOS FlashBack™ button
– BIOS FlashBack™ LED
– Clear CMOS button
– ProCool II
– Pre-mounted I/O shield
– SafeSlot
– SafeDIMM
:Bespoke Motherboard Design & Business Focused Features
– 24/7 Reliability
– Overcurrent Protection
|
| תוכנות מצורפות |
:ASUS Exclusive Software
Armoury Crate
– Fan Xpert 4
ASUS CPU-Z
IT Management software supported
– ASUS Control Center Express(ACCE)
Adobe Creative Cloud (Free Trial)
Norton 360 Deluxe (60 Days Free Trial)
WinRAR (40 Days Free Trial)
:UEFI BIOS
ASUS EZ DIY
– ASUS CrashFree BIOS 3
– ASUSTeK. EzFlash Utility
– FlexKey
|
| אביזרים כלולים |
:Cables
2x SATA 6Gb/s cables
1x CPU 8-pin to PCIe 8-pin adapter cable package
1x Thermistor cable pack
:Miscellaneous
1x ASUS WiFi Q-Antenna
1x M.2 Q-Latch package(2 in 1)
2x M.2 Rubber Packages
1x Q-connector
:Documentation
1x ACC Express Activation Key Card
1x QSG
|
| תצורה |
CEB Form Factor
12inch x 11 inch
(30.5 cm x 28.3 cm)
|
| קישור לאתר היצרן |
https://www.asus.com/motherboards-components/motherboards/workstation/pro-ws-trx50-sage-wifi/
|
